Microwave Sintering Furnace

Department: Department of Industrial and Production Engineering
Concerned Person:
Name Mr. MARADANI SIMHACHALAM
Technical Assistant
Department of Industrial and Production Engineering
Email ID maradanis@nitj.ac.in
Mobile No. 08639185650
Location:

Room No. WE-106, First Floor, New Workshop

Available For:

For Internal Users only

Major Specifications:
Parameter Specification
Application Heat treatment and sintering of ferrous and non-ferrous materials under controlled atmosphere
Heating Technology Microwave heating with SiC susceptor
Microwave Power & Frequency 3 kW, 2.45 GHz (Single magnetron)
Input Power Supply 1-Phase, 50 Hz
Rated Voltage 220 VAC
Rated Power 3 kW
Maximum Temperature Up to 1500 °C
Operating Temperature Range 300 – 1500 °C
Heating Rate 20 – 60 °C/min
Temperature Stability ±1%
Temperature Controller PID controller
Temperature Measurement Non-contact infrared pyrometer with adjustable emissivity & digital display
Key Feature Rapid and uniform heating using high-quality SiC susceptor
Research Potential:

Yes
