Particulates (mass concentration)

Sensor Type: Light Scattering/Integrating Photometer

Display Resolution: 0.001 mg/m³

Display Range: 0 to 200 mg/m³

Particulate Size Range: 0.1 to 10 µm

Accuracy Repeatability: +/-15%

Carbon Dioxide

Sensor Type: NDIR

Range: 0-5,000 ppm

Resolution: 1ppm

Accuracy: +/-100 ppm

VOC

Sensor Type: PID

Range: 0-2,000 ppm

Resolution: 0.01 ppm

Accuracy: +/- 5%

Hydrogen Sulfide

Sensor Type: Electrochemical

Range: 0-500 ppm

Resolution: 1 ppm

Accuracy: +/- 5%

Carbon Monoxide

Sensor Type: Electrochemical

Range: 0-1000 ppm

Accuracy: +/-5%

Resolution: 1 ppm

Chlorine

Sensor Type: Electrochemical

Range: 0-20 ppm

Accuracy: +/-5%

Resolution: 0.1 ppm

Nitric Oxide

Sensor Type: Electrochemical

Range: 0-100 ppm

Accuracy: +/- 5%

Resolution: 0.1 ppm

Nitrogen Dioxide

Sensor Type: Electrochemical

Range: 0-50 ppm

Accuracy: +/- 5%

Resolution: 0.1 ppm

Sulphur Dioxide

Sensor Type: Electrochemical

Range: 0-50 ppm

Accuracy: +/- 5%

Resolution: 0.1 ppm

Relative Humidity

Range: 0-100% Rh

Accuracy: +/- 5% RH

Resolution: 0.1 % RH

Temperature

Range: 0-60 °C

Accuracy: +/- 1.1 °C

Resolution: 0.10 °C

Particulate Impactors Size Fractions

PM2.5, PM4, PM10, TSP

Flow Rate

≥ 1.5 L/min

Aerosol Conditioning

Co-axial 3 channel diffusion dryer should be supplied along with the instrument.
